Features
Specifications
OPS – General Features
CPU
Intel® Core™ i5-10210U 4 cores, 8 threads 1.6GHz (Up to 4.2 GHz w/ Turbo Boost)
Chipset
Cometlake SoC 6MB L3 Cache
Resolution Support
Ultra HD Up to 4096 x 2160@60Hz
GPU
Intel® UHD Graphics 10th gen
Memory
2 x 4 GB SO-DIMM DDR4
Network
LAN: 10/100/1000 Mbps WLAN: 802.11 a/g/n Bluetooth 4.0
Storage
256GB SSD
I/O Ports
1 x RJ45 1 x USB2.0 1 x USB3.0 2 x USB3.1 1 x USB Type-C 1 x HDMI out 1 x Line out 1 x Mic in 2 x WiFi antenna connector 1 x Power button
Operating System
Windows 11 Pro
Mechanical
Product Dimensions (WxDxH)
180 x 119 x 30 mm
Package Dimensions (WxDxH)
237 x 180 x 59 mm
Product Weight
0.85 kg
Package Weight
1.05 kg
Environmental Conditions
Operating Temperature
0-40°C
Operating Humidity
95%
Power
Voltage, HZ
12~19V
Power Supply
DC-In
Features
Main Features
Wake-on-LAN Support, Watchdog Timer
Certification
Safety
YES
EMC
YES
CE
YES
* Specifications are subject to change without prior notice.
